UDP900 Mark II
£3,399.00
Skip to product information
Roon Ready In Certification
Fully Redesigned Audio Utilizing Dual ESS9038PRO DAC’s
TMDS Retiming On HDMI Audio Port
Enhanced USB 3.0 System With Isolated Power
XMOS Supports PCM768/512 DSD
Upgraded Copper Wiring And Amphenol/JST Connectors
Control 4 Support
Crestron Support
Wake-Up On Lan
High-quality copper-core wires are used throughout the device, the in-machine PCB connectors have been upgraded to JST and Amphenol brands, enhancing the stability and reliability of the connections.
The ESS9038PRO D/A decoder offers stereo and multi-channel outputs. With XMOS USB Audio input capable of handling PCM768 and DSD512, UDP900 MKII offers premium audio output. The TMDS retiming function on the HDMI AUDIO port also refines audio quality.
Adding a USB3.0 HUB chip and redesign the USB3.0 power supply to improve the compatibility and stability of the USB3.0 port, so as to better adapt to USB flash drives and hard drives. The optimization also enhances the stability of data transmission and increases the transmission speed, thus achieving better sound and picture effects.
Replacing the operational amplifiers with seven OPA1602s. Its low noise reduces audio distortion for clearer sound. High precision ensures accurate signal reproduction, creating audiophile-grade sound.
Specifications:
- UHD Blu-ray, Blu-ray, Blu-ray 3D, DVD-Video, DVD-Audio, AVCHD, SACD, CD, Kodak Picture CD, CD-R/RW, DVD±R/RW, DVD±R DL, BD-R/RE
- Analog audio: stereo
- Independent stereo analog audio: XLR balanced output, RCA output
- Optical/coaxial audio: up to 2 channels /192kHz PCM, Dolby Digital, DTS
- HDMI audio: up to 7.1 channel /192kHz PCM, up to 5.1 channel DSD, Bitstream
- HDMI video: UHD 23.976/25/30/50/59.94/60hz, 1080 I/P, 720P, 576I/P, 480I/P, source direct.
- Frequency range: 20Hz-20kHz (±0.05dB)
- Signal-to-noise ratio: ≥120dB
- Total harmonic distortion + Noise: ≤0.01%
- Output level: (RCA) 2. 1±0.2Vrms; (XLR) 4.2±0.4Vrms
- Dynamic range: AGT: ≥120dB
- Channel separation: ＞100dB (RCA); ＞120dB (XLR
- Power supply: AC 110-120V ~ 50/60Hz / AC 220-240V ~ 50/60Hz
- Power consumption: <40W, Standby<0.5W
- Dimensions: 445 x 321 x 133 mm
- Weight: 15.4kg
- Operating Temperature: 5°C~ 35°C (41°F ~ 95°F)
- Operating Humidity: 15% ~ 75%
