X3 Series 2 Integrated Amplifier
Rotel Michi X3 Series 2 Integrated Amplifier
Brand: Rotel Michi
Type: Integrated Amplifiers
ON DEMONSTRATION
Elegant, efficient, uncompromised. The Michi X3 Series 2 Integrated Amplifier combines 350 Watts of robust Class AB output power and an 8-Channel ESS SABRE Digital to Analog converter to deliver a refined and expansive performance. Analog RCA, XLR, Moving Magnet Phono, aptX™ HD Bluetooth, Coaxial, Optical, and PC-USB rendering MQA are all supported.
The Michi X3 Series 2 Integrated Amplifier delivers an unparalleled listening experience rendering audio with exceptional accuracy, refinement and detail on an expansive soundstage, courtesy of 350 Watts of robust Class AB output power and an 8-Channel ESS SABRE ES9028PRO Digital to Analog converter.
The elegant industrial design of the Michi X3 Series 2 is at home in any living space, and its 350 watts of Class AB output power pairs with nearly any loudspeaker. Analog, Digital, PC-USB (MQA, PCM, DSD), XLR Balanced, and wireless aptX™ HD Bluetooth sources are all supported, and a Moving Magnet Phono Stage is included for vinyl lovers.
Performance engineered, acoustically refined, and meticulously manufactured to be operated with ease by music lovers and audiophiles alike.
Michi, expectations amplified.
Specification
INTERMODULATION DISTORTION (60Hz:7kHz, 4:1)
<0.03%
DAMPING FACTOR (20Hz - 20kHz, 8Ω)
350
CHANNEL SEPARATION
>55dB
INPUT SENSITIVITY
Line Level Inputs (RCA): 340mV
Line Level Inputs (XLR): 540mV
Phono Input (MM): 5.2mV
INPUT IMPEDANCE
Line Level Inputs (RCA): 100kΩ
Line Level Inputs (XLR): 100kΩ
Digital Inputs: 75Ω
Phono Input (MM): 47kΩ
INPUT OVERLOAD
Line Level Inputs (RCA): 3.5V
Line Level Inputs (XLR): 5.5V
Phono Input: 60mV
PREOUT LEVEL
1.9V
OUTPUT IMPEDANCE
100Ω
TONE CONTROLS
±10dB at 100Hz / 10kHz
COAX/OPTICAL DIGITAL INPUT SIGNALS
SPDIF LPCM (Up to 24-bit/192kHz)
PC-USB
USB Audio Class 1 (up to 24-bit/96kHz)
USB Audio Class 2 (up to 32-bit/384kHz)*
*Driver installation required
DSD and DoP support
MQA and MQA Studio support
Roon Tested support
DIMENSIONS (W × H × D)
485 x 150 x 452mm
19" × 6" × 17 3/4"
FRONT PANEL HEIGHT
132 mm (5.25")
POWER REQUIREMENTS
230V, 50Hz
POWER CONSUMPTION
500W
STANDBY POWER CONSUMPTION
Normal: <0.5W
Network Wakeup: <2W
NET WEIGHT
28.9kg (63.7 lbs.)
BTU RATING
1303 BTU/h
