Perlisten Audio Perlisten Audio S5i-C In-Wall Speaker (single)

Perlisten Audio S5i-C

Based largely on the S5m. Here we have adapted the design for inwall applications. Shallow 4” mounting depth and integral aluminum extrusion rear enclosure insure consistent performance and minimal sound propagation to adjacent rooms. Featuring the proprietary DPC-Array controlling Mid/High frequencies, centered by a 28mm Beryllium dome and dual 28mm TPCD ultra-lightweight domes. All transducers are developed ground up by Perlisten engineers – bringing decades of research, culminating in this world class design. Teaming up with companies in the USA and Sweden to bring modern material science to hi-fi. Utilizing advanced Comsol acoustic modeling, the DPC-array is the result of 18 months of painstaking simulations and prototyping. The result is one of the most technologically advanced loudspeakers available. This new tweeter/waveguide DPC-Array delivers amazing accuracy, smoothness, and directivity control to handle the critical vocal range and delicate treble. All S-Series speakers share the same DPC-Array and benefit from unique timbre matching technique across the entire series. Another Perlisten in-wall loudspeaker to be certified for THX Dominus – their highest rating.

Specification

Enclosure Alignment: 3-way acoustic suspension

Driver complement: DPC Array: 28mm

Beryllium, 28mm (2) Textreme TPCD; Woofers: 180mm (2)

Textreme TPCD Sensitivity: 91.9dB / 2.83V / 1.0m

Impedance: 4Ω nominal / 3.4Ω min

Response Linearity: 80 - 20kHz +/-1.5dB window

Frequency Response (-10dB): 52 - 37kHz

Typical In Room bass extension: 46Hz

Dimensions (HxWxD): 624 x 257 x 101.7mm

Mounting Dimensions (HxWxD): 624 x 257 x 101.7mm

Weight: 15.9 kg

Recommended Amplifier Power: 100 - 350W RMS SPL capability @1m (100-20kHz): 117.3dB peak; 117.0dB peak <3% 2nd, 3rd

Harmonics Certification: THX Dominus
